Jumbo Rock Drill Spare Parts 200MM Long 6063 T6 Aluminium Extruded Profiles Customized For Rock Drilling Rig

Jumbo Rock Drill Spare Parts 200MM Long 6063 T6 Aluminium Extruded Profiles Customized For Rock Drilling Rig

aluminum extrusion profiles

aluminium extrusion bar

Place of Origin:

CHINA

Brand Name:

HUANYU

Model Number:

HYH200MM

Contact Us

Request A Quote
Product Details
Length:
385CM
Density:
2.78 G/cc
Ultimate Tensile Strength:
186 MPa
Yield Tensile Strength:
145 MPa
Melting Point:
616-654 Celsius Degree
Elongation At Break Percentage:
18%
Application:
Mining Industry
Payment & Shipping Terms
Minimum Order Quantity
5 METRIC TONS
Price
NEGOTIABLE
Packaging Details
PALLET
Delivery Time
40 days
Payment Terms
T/T
Supply Ability
70 METRIC TONS PER MONTH
RELATED PRODUCTS
Contact Us
86-023-65820299-104
Contact Now
Product Description

Jumbo Rock Drill Spare Parts 200MM Long 6063 T6 Aluminium Extruded Profiles Customized For Rock Drilling Rig



Holder For Atlas 281 282 JUMBO BOOMER





6063 is often called architectural aluminum for two reasons. First, it has a surface finish that is far smoother than the other commercially available alloys. Second, its strength is significantly less than most other aluminum alloys.





Specifications on High Strength 6063 T6 Extruded Profiles Used As Constructional Wall

Wall Thickness: 18.70mm

Shape: Customized

Length: 4200mm

6063 Typical Chemical Composition %
Weight % Si Fe Cu Mn Mg Cr Zn Ti Each Total
Minimum 0.20       0.45
Maximum 0.60 0.35 0.10 0.10 0.90 0.10 0.10 0.10 0.05 0.15

Remainder Aluminum




6063 Typical Mechanical Properties
Temper Tensile Hardness
  Ultimate Yield Elongation Brinell
  KSI MPA KSI MPA %
T5, T52 27 186 21 145 12 60
T6 35 241 31 214 12 73

Jumbo Rock Drill Spare Parts 200MM Long 6063 T6 Aluminium Extruded Profiles Customized For Rock Drilling Rig 0Jumbo Rock Drill Spare Parts 200MM Long 6063 T6 Aluminium Extruded Profiles Customized For Rock Drilling Rig 1Jumbo Rock Drill Spare Parts 200MM Long 6063 T6 Aluminium Extruded Profiles Customized For Rock Drilling Rig 2Jumbo Rock Drill Spare Parts 200MM Long 6063 T6 Aluminium Extruded Profiles Customized For Rock Drilling Rig 3Jumbo Rock Drill Spare Parts 200MM Long 6063 T6 Aluminium Extruded Profiles Customized For Rock Drilling Rig 4
